Description
Cooler Master CMP 520L computer case (black)
Cooler Master CMP 520L is a classic yet functional PC case that is perfect for gaming configurations and more. Its asymmetrical mesh front panel allows for efficient airflow and acts as a dust filter, while the spacious design provides freedom to mount the components of your choice. With full compatibility with Mini-ITX, Micro-ATX and ATX motherboards, this model provides a versatile base for expansion.
Take care of reliable cooling
The CMP 520L can support up to six fans (front, rear and top). It also supports water coolers up to 280 mm at the front, 240 mm at the top (with RAM heights below 35 mm) or 120 mm at the rear. This way you don't have to worry about your computer overheating! The kit includes one MasterFan Lite fan pre-installed on the back of the case. The whole set ensures efficient cooling of components, even in more demanding configurations.
Space for high-performance components
The case offers space for a graphics card up to 350 mm long, a CPU cooler up to 161 mm high and an ATX PSU up to 160 mm. There are also two spaces for 3.5" / 2.5" HDDs and two for 2.5" SSD media. Behind the motherboard tray, 18.5 mm of space is provided for orderly cable routing - so you can easily take care of the aesthetics of your computer's interior.
Thoughtful design and aesthetics
The CMP 520L is distinguished by its minimalist black finish and ventilated PSU cover, which allows the installation of both actively cooled (with the fan pointing up or down) and passively cooled units. In addition, a side panel made of tempered glass allows the computer's interior to be showcased, while bottom and top dust filters make it easy to keep the case clean.
| Manufacturer |
Cooler Master |
| Model |
CP520-KGNN-S03 |
| Color |
Black |
| External materials |
Steel, plastic |
| Side panel |
Tempered glass |
| Dimensions (with protruding parts) |
439 × 204 × 463 mm |
| Dimensions (without protruding parts) |
432 × 204 × 448 mm |
| Motherboard standard |
Mini-ITX, Micro-ATX, ATX |
| Expansion card slots |
7 |
| 5.25" bays |
0 |
| 2.5"/3.5" HDD bays |
2 |
| 2.5" SSD bays |
2 |
| Connectors |
1x USB-A 3.2 Gen 1, 1x USB-A 2.0, 1x 3.5mm combo jack (headphone output / microphone input) |
| Factory-installed fans |
Rear: 1x MasterFan Lite; |
| Fan mounting options |
Top: 2x 120 mm / 2x 140 mm; Front: 3x 120 mm / 2x 140 mm; Rear: 1x 120 mm; |
| Water cooling mounting options |
Top: 120 mm / 240 mm*; Front: 120 mm / 240 mm / 140 mm / 280 mm; Rear: 120 mm; *For RAM height below 35 mm. |
| Max CPU cooling height |
161 mm |
| Max PSU length |
160 mm |
| Max. length of graphics card |
350 mm (excluding front fans and water cooling) |
| Space for cabling behind the motherboard tray |
18.5 mm |
| Dust filters |
Top, bottom |
| PSU support |
ATX, bottom mount |
